| Attribute | Value |
|---|---|
| Product Name | Neles ND7000 series intelligent valve controller |
| Temperature range | -40 ... +85 °C / -40 ... +185 °F, standard version |
| Communication | HART |
| Protection class | IP66 / NEMA 4X enclosure |
| Diagnostics | Yes |
| Applications | General |
| Condition | New |
The Valmet Neles ND7106HX8T Intelligent Valve Controller Positioner is a cutting-edge solution designed for precise control valve actuation in industrial processes. Combining advanced diagnostics, robust construction, and seamless integration with automation systems, this device ensures optimal performance, energy efficiency, and long-term reliability. It is ideal for applications requiring high accuracy and adaptability in harsh environments.
| Parameter | Specification |
|---|---|
| Communication | HART, FOUNDATION Fieldbus, PROFIBUS PA |
| Power Supply | Loop-powered (4-20 mA) |
| Temperature Range | Standard: -40°C to +85°C Arctic: -53°C to +85°C |
| Protection Class | IP66 / NEMA 4X |
| Actuator Compatibility | Rotary (45-95°) / Linear (10-120 mm) |
| Weight | 3.4 kg |
| Certifications | SIL 2, ATEX, IECEx |
