Rosemounte 3301 Level Transmitter Guided Wave Radar 3301HA1S1V3A 3300 Series

1
MOQ
1300USD~3800USD
السعر
Rosemounte 3301 Level Transmitter Guided Wave Radar 3301HA1S1V3A 3300 Series
ميزات صالة عرض منتوج وصف طلب عرض أسعار
ميزات
مواصفات
حساسية: ما يصل إلى 150: 1
وزن: يعتمد على أداة محددة
المواد المبللة: الفولاذ المقاوم للصدأ 316 / 316L و CF3M
معدل التحديث اللاسلكي: 1 ثانية. إلى 60 دقيقة، يمكن اختياره من قبل المستخدم
نطاق القياس: ما يصل إلى 2000 رطل لكل بوصة مربعة (137,89 بار) تفاضلي
بروتوكول الاتصال: 4-20 مللي أمبير هارت
نطاق درجة الحرارة: -200 درجة مئوية إلى +850 درجة مئوية
نطاق القياس: رقمية أو تناظرية
معلومات اساسية
مكان المنشأ: الصين
اسم العلامة التجارية: Rosement
رقم الموديل: روزماونت 3301
شروط الدفع والشحن
تفاصيل التغليف: صندوق خشبي/صندوق كرتون
وقت التسليم: 6-8 اسابيع
شروط الدفع: exw
القدرة على العرض: 300pcs/شهر
منتوج وصف
Product Details

The Rosemount 3301 Guided Wave Radar Level Transmitter provides reliable and accurate measurement of level and interface in liquids, slurries, and solids. Using guided wave radar (GWR) technology, it is unaffected by changes in process conditions such as temperature, pressure, density, or vapor. Designed for challenging environments, the Rosemount 3301 improves process safety, reduces downtime, and ensures consistent monitoring in critical industrial applications.


Features
  • Guided wave radar technology for continuous level measurement
  • High accuracy independent of temperature, pressure, or vapor changes
  • Robust probe design for long-term durability
  • Suitable for both liquid and solid applications
  • Maintenance-free with no moving parts
  • Easy installation and configuration
  • Compatible with HART communication for remote monitoring

Specifications
  • Measurement Principle: Guided Wave Radar (GWR)
  • Media Compatibility: Liquids, slurries, solids
  • Output Signal: 4–20 mA with HART protocol
  • Measuring Range: Up to 20 m (65 ft) depending on probe
  • Accuracy: ±5 mm
  • Temperature Range: -40 °C to +200 °C (-40 °F to +392 °F)
  • Pressure Range: Vacuum to 40 bar (580 psi)
  • Housing Material: Aluminum or stainless steel
  • Certifications: ATEX, FM, IECEx, SIL-rated

Applications
  • Oil and gas storage tanks
  • Chemical and petrochemical plants
  • Water and wastewater treatment
  • Power generation plants
  • Food and beverage manufacturing
  • Pharmaceutical production facilities

FAQ

Q1: What industries typically use the Rosemount 3301?
A1: It is widely applied in oil & gas, chemicals, water treatment, power generation, and food industries.

Q2: Does it work with solids and slurries?
A2: Yes, the Rosemount 3301 is designed for reliable operation in liquids, slurries, and solids.

Q3: What communication protocols are available?
A3: The transmitter supports 4–20 mA with HART communication.


Contact Us

For product inquiries, technical support, or quotations:
edward.zhao@gongboshi.com
+86-21-56633922
www.shgongboshi.com


Related Products
  • Rosemount 5300 Series Guided Wave Radar Level Transmitter
  • Rosemount 5400 Non-Contact Radar Level Transmitter
  • Rosemount 3144S Temperature Transmitter
  • Emerson 3308 Wireless Guided Wave Radar

Tags

Rosemount 3301, Guided Wave Radar, Rosemount Level Transmitter, Radar Level Measurement, Emerson Rosemount, Tank Level Sensor, Industrial Process Automation
