Rosemountt 5408 Level Transmitter Original Level Sensor Gauge Model 5408A1SHS1E11R4AACAB3M5Q4

1
MOQ
1536-1836$
السعر
Rosemountt 5408 Level Transmitter Original Level Sensor Gauge Model 5408A1SHS1E11R4AACAB3M5Q4
ميزات صالة عرض منتوج وصف طلب عرض أسعار
ميزات
مواصفات
نطاق الضغط: ما يصل إلى 40 بار
إشارة التحكم: 4-20 مللي أمبير / 0-10 فولت
شرطي: جديد
نوع الاتصال: شفة ، موضوع
دعم البروتوكول: هارت ، مؤسسة Fieldbus ، Profibus PA
المصنع: مختلف الشركات المصنعة
طلب: العمليات الصناعية
مزود الطاقة: AC أو DC
معلومات اساسية
مكان المنشأ: شنغهاي
اسم العلامة التجارية: Rosemount
إصدار الشهادات: QC
رقم الموديل: 5408
شروط الدفع والشحن
تفاصيل التغليف: صندوق خشبي/صندوق كرتون
وقت التسليم: 8 أسابيع
شروط الدفع: exw
القدرة على العرض: 300pcs/شهر
منتوج وصف
Product Details

The Rosemount 5408 Level Transmitter Original is a non-contacting radar level measurement device designed for the most demanding process industries. With its advanced FMCW radar technology, it delivers accurate and reliable level measurements for liquids, solids, and harsh process conditions. Emerson’s proven design ensures high performance, simple installation, and long service life.


Key Features
  • Non-contacting radar technology for continuous and safe measurement
  • High accuracy and stability even in challenging conditions
  • Maintenance-free design with no moving parts
  • Easy integration with existing control systems via HART® or FOUNDATION™ Fieldbus
  • Versatile applications across water treatment, oil & gas, chemicals, and food & beverage industries
  • Safety compliant with SIL-certified versions for critical operations

Technical Specifications
  • Measurement Principle: FMCW Non-contacting Radar
  • Measuring Range: Up to 50 meters (depending on application)
  • Process Temperature: -40 °C to +130 °C (-40 °F to +266 °F)
  • Process Pressure: Up to 40 bar (580 psi)
  • Accuracy: ±2 mm
  • Communication Protocols: 4–20 mA/HART®, FOUNDATION™ Fieldbus
  • Enclosure Rating: IP66/67, NEMA 4X

Applications
  • Oil & Gas storage tanks
  • Water and wastewater treatment plants
  • Chemical storage vessels
  • Food and beverage process tanks
  • Mining and bulk solids handling
  • Power generation and utilities

FAQ

Q1: What makes the Rosemount 5408 different from other radar transmitters?
The 5408 uses advanced FMCW radar technology, ensuring high accuracy and reliable performance even in demanding applications.

Q2: Can the 5408 handle solid level measurements?
Yes, it is designed to measure both liquids and solids, making it versatile for different industries.

Q3: Does the Rosemount 5408 require frequent maintenance?
No, the non-contacting design eliminates moving parts, reducing the need for maintenance.


Contact Us

For inquiries, technical support, or quotations on the Rosemount 5408 Original Level Transmitter, please contact us:

Email: edward.zhao@gongboshi.com
Phone: +86-21-80392064
Website: www.shgongboshi.com


Related Products
  • Rosemount 5300 Series Guided Wave Radar Level Transmitter
  • Rosemount 3300 Series Level Transmitter
  • Rosemount 5900C/S Radar Level Gauges
  • Emerson 5408:SIS Safety Certified Transmitter
