The Bopp & Reuther Density Concentration Meter is a robust, inline sensor for continuous density and concentration control in high-pressure industrial processes. Using oscillating U-tube technology, it measures with ±0.0001 g/cm³ accuracy, handling pressures up to 100 bar and viscosities to 20,000 mPa·s. The meter's stainless steel construction and digital outputs make it suitable for real-time monitoring in pipelines, ensuring product quality in petrochemical, food, and pharmaceutical sectors. With low maintenance and hazardous area certification, it supports reliable, cost-effective density management.
| Parameter | Specification |
|---|---|
| Measuring Principle | Oscillating U-Tube |
| Density Range | 0.5 to 3 g/cm³ |
| Accuracy | ±0.0001 g/cm³ |
| Repeatability | ±0.00005 g/cm³ |
| Temperature Range | -40°C to +200°C |
| Pressure Rating | Up to 100 bar |
| Viscosity Range | Up to 20,000 mPa·s |
| Output Signals | 4-20 mA, HART, Profibus |
| Certifications | ATEX, IECEx |
What is the U-tube principle?
Oscillation frequency proportional to density.
How accurate is it?
±0.0001 g/cm³ for high precision.
Is it for high pressure?
Yes, up to 100 bar.
Does it compensate temperature?
Yes, integrated compensation.
Is it hazardous area safe?
Yes, ATEX and IECEx certified.
