Stock Pressure Regulator Fisher 1301F 1301G Type Self-operated High Pressure Industrial Reducing Valves Supplier

The Fisher 1301F and 1301G are compact, direct-operated pressure reducing regulators. They take high inlet pressure and deliver steady lower outlet pressure for instrument air, gas supply or small flow applications. The 1301F is the standard model, while 1301G has a built-in relief valve for added safety. These regulators are simple, rugged and widely used where reliable pressure control is needed without complexity.

• Direct-operated – no pilot or external power required
• Compact and lightweight design
• Built-in relief valve on 1301G model
• Adjustable outlet pressure with easy knob
• Stainless steel trim for corrosion resistance
• High inlet pressure capability

• Inlet Pressure Range: Up to 6000 psig (414 bar)
• Outlet Pressure Ranges: 10 to 225 psig (0.69 to 15.5 bar)
• Body Sizes: 1/4 inch NPT
• Body Materials: Aluminum or stainless steel
• Temperature Capabilities: -40 °F to +180 °F (-40 °C to +82 °C)
• Relief Valve Set Point (1301G): 10–15 psi above set pressure
• Flow Capacity: Suitable for instrument air and small loads

• Instrument air supply
• Natural gas supply to small regulators
• Pilot supply for larger regulators
• Laboratory and test equipment

• Fisher 67C series regulators
• Fisher 95 series high-pressure regulators
• Fisher 627 series regulators
