Fisher 1098-EGR Pilot-Operated Natural Gas Pressure Reducing Valve with High Accuracy for Industrial Use

Fisher 1098-EGR is a pilot-operated pressure reducing regulator designed for accurate control of natural gas, air, and other non-corrosive gases. It uses a Type 6358 pilot to maintain stable downstream pressure even with large variations in inlet pressure or flow demand. This regulator is widely used in gas distribution stations, industrial plants, and commercial applications where tight pressure control and high capacity are needed.

• Pilot-operated for high accuracy and low droop
• Balanced valve plug design – minimal setpoint shift
• High flow capacity with soft-seat tight shut-off
• Easy pilot adjustment and maintenance
• Internal relief option available
• Wide range of outlet pressure settings
• Robust steel or cast iron body

• Body Sizes: NPS 1 to 12 (DN 25 to 300)
• End Connections: NPT, CL125 FF, CL250 RF, PN 16/25/40
• Maximum Inlet Pressure: Up to 1500 psig (103 bar) depending on body size
• Outlet Pressure Range: 3 to 500 psig (0.21 to 34.5 bar) – pilot dependent
• Temperature Capabilities: -20 °F to 180 °F (-29 °C to 82 °C) standard
• Body Materials: WCC steel, LCC steel, ductile iron
• Orifice Sizes: Multiple available for flow matching

• Natural gas city gate stations
• Industrial gas pressure reduction
• Commercial metering and distribution
• Burner and furnace gas supply
• District regulator stations
